UL3348
UL3348 single-conductor wire with XLPE insulation, UL-certified and rated 80°C/600V. Provides heat resistance, voltage stability, and flame performance for internal wiring.
UL3348 XLPE Insulated Wire– 80°C / 600V Halogen-Free Hook-Up Wire for Internal Wiring Applications
UL3348 is a UL-certified single-conductor wire insulated with cross-linked polyethylene (XLPE). Rated for 80°C and 600V, this wire is designed for internal wiring in electronic and electrical equipment where heat resistance, voltage stability, and flame performance are critical.
Key Features
Conductor: Solid or stranded bare or tinned copper, available in sizes from 26 AWG to 10 AWG
Insulation: Extruded XLPE with a minimum average thickness of 0.76 mm
Temperature Rating: Up to 80°C
Voltage Rating: 600V
Flame Resistance: Passes horizontal flame test requirements
Standards: Complies with UL 758 Appliance Wiring Material (AWM) Style 3348
Usage: Designed for internal wiring in electronic and electrical equipment
Common Applications
Internal wiring in electronic devices and instrumentation
Applications requiring moderate heat resistance and high-voltage performance
Internal connections in industrial control panels and machinery
External Technical Reference
Need assistance selecting the right wire?
Our technical team is ready to help you choose the best UL3348 cable for your project.
