UL3288 XLPE Insulated Wire
UL3288 high-temp hook-up wire with XLPE insulation, UL-certified and rated 150°C/600V. Halogen-free, RoHS-compliant, and ideal for electronics, energy, HVAC, and power systems.
UL3288 XLPE Insulated Wire – 150°C / 600V Hook-Up Wire for High-Temperature & Halogen-Free Applications
UL3288 is a high-temperature, high-voltage hook-up wire insulated with cross-linked polyethylene (XLPE) and certified under UL AWM Style 3288. Rated for continuous use at 150°C and up to 600V, this wire delivers excellent thermal performance, dielectric strength, and chemical resistance—ideal for demanding applications in electronics, energy, HVAC, and power control systems.
Its halogen-free and RoHS-compliant insulation makes it a preferred choice for manufacturers prioritizing environmental safety and low-smoke flame behavior.
Features
Conductor: Solid or stranded bare/tinned copper
Size Range: 30 AWG to 4/0 AWG
Insulation: XLPE, nominal thickness 0.76 mm (30 mils)
Temperature Rating: 150°C
Voltage Rating: 600V AC / 750V DC
Flame Test: UL VW-1, CSA FT1 vertical flame test compliant
Compliance: UL 758 AWM, RoHS, REACH, Halogen-Free
Performance Benefits
Thermal Endurance: Designed for high-heat environments with stable insulation
Mechanical Strength: Resists abrasion, pulling, and compression
Chemical Resistance: Withstands oils, fuels, solvents, and moisture
Eco-Friendly: Halogen-free insulation supports clean combustion and reduced toxic smoke
Low Smoke Emission: Safer for confined spaces, control panels, and indoor systems
Application Areas
Internal wiring in control panels, switchgear, and energy storage systems (ESS/BBU)
Inverters, drives, and power modules in automation or renewable energy equipment
High-temperature wiring in medical devices, LED drivers, industrial motors, and lighting systems
Environmental control systems: HVAC, building automation, transportation electronics
External Technical Reference
Expert Support Available
Need help selecting the correct UL3288 wire or customizing jacket colors and striping?
