Features

• Conductor: Solid or stranded bare or tinned copper

• Wire Sizes: Typically available in 18 AWG to 16 AWG (other sizes upon request)

• Insulation Material: Low-smoke, halogen-free cross-linked polyethylene (XLPE)

• Nominal Insulation Thickness: 1.52 mm (60 mils), minimum 1.37 mm (54 mils)

• Voltage Rating: 600V

• Temperature Rating: Continuous use up to 125°C

• Flame Retardance: Complies with UL Horizontal Flame Test

• Environmental Compliance: RoHS, REACH, halogen-free certified

• UL Style: UL 3297 (Appliance Wiring Material, AWM)

 Performance Advantages

• Halogen-Free Safety: Produces minimal toxic smoke in case of fire, suitable for confined or sensitive installations

• Excellent Thermal Performance: Reliable operation under sustained heat loads

• Chemical Resistance: Resistant to oils, solvents, and cleaning agents

• Long-Term Stability: Maintains insulation integrity in environments with thermal cycling and vibration

• Sustainable and Compliant: Meets modern ESG requirements and eco-focused specifications

Application

• Internal power or signal wiring in medical devices, server cabinets, and EV chargers

• Use in HVAC systems, lighting controllers, building automation, and switchgear panels

• Wiring in railway systems, public transportation infrastructure, or aircraft interiors

• Ideal for OEM harnesses requiring high thermal class and fire-safe insulation
