UL3223 High-Temperature Silicone Wire
UL3223 lead wire with fine-stranded tinned copper and silicone insulation. Offers flexibility, heat resistance, and reliable electrical insulation for internal wiring.
UL3223 High-Temperature Silicone Wire｜150°C 300V Flexible Insulated Cable｜UL Certified
UL3223 is a single-conductor lead wire featuring a fine-stranded tinned copper conductor and flexible silicone rubber insulation. It is designed for internal wiring applications requiring excellent heat resistance, electrical insulation, and mechanical flexibility.
Key Features
- Conductor: Stranded Tinned Copper
- Insulation: Silicone Rubber
- Rated Temperature: 150°C
- Rated Voltage: 300V
- Flame Resistance: VW-1 Flame Test compliant
- Flexibility: Excellent for dynamic routing and compact installations
- RoHS / REACH Compliant: Yes
Typical Applications
- Internal wiring of household appliances
- Electronic device assemblies
- Industrial automation equipment
- Wiring for sensors, controllers, and actuators
- LED lighting systems exposed to heat
Need assistance selecting the right wire? Our technical team is ready to help you choose the best cable for your project.
