UL3347 single-conductor wire with XLPE insulation, UL-certified and rated 80°C/300V. Ensures heat resistance, voltage stability, and flame performance for internal wiring.


UL3347 XLPE Insulated Wire – 80°C / 300V Hook-Up Wire for Internal Wiring Applications

UL3347 is a UL-certified single-conductor wire insulated with cross-linked polyethylene (XLPE). Rated for 80°C and 300V, this wire is designed for internal wiring in electronic and electrical equipment where heat resistance, voltage stability, and flame performance are critical.


Key Features

  • Conductor: Solid or stranded bare or tinned copper, available in sizes from 32 AWG to 16 AWG

  • Insulation: Extruded XLPE with a uniform thickness of 0.47 mm

  • Temperature Rating: Up to 80°C

  • Voltage Rating: 300V

  • Flame Resistance: Passes horizontal flame test requirements

  • Standards: Complies with UL 758 Appliance Wiring Material (AWM) Style 3347

  • Usage: Designed for internal wiring in electronic and electrical equipment


 Common Applications

  • Internal wiring in electronic devices and instrumentation

  • Applications requiring moderate heat resistance and low-voltage performance

  • Internal connections in compact or precision electronic systems

 External Technical Reference

Need assistance selecting the right wire?

Our technical team is ready to help you choose the best UL3347 cable for your project.
